Railway EMC-1 Cable Glands

Designed for railway applications, ensuring reliable electromagnetic
compatibility (EMC) performance.

Complies with EN45545-2 fire safety standard

Maintains effective sealing against dust, moisture, and environmental exposure

Cap/Body Material	Nickel Plated Brass
Seal Material	EPDM
Clamping Insert Material	Polyamide 6 V2 acc. to UL 94
O-Ring Material	EPDM
Ingress Protection Rating	IP68 - 5 Bar 30 min, IP66
Flammability	R22 acc.to EN45545-2 R23 acc.to EN45545-2 HL2 acc.to EN45545-2 HL3 acc.to EN45545-2
Temperature Range	Permanent -40 °C to +100 °C
Thread Type	Metric
Accessories	EMC Locknuts Dome plugs Gaskets (Washers)
Remarks	All accessories must be ordered separately.
