Virgo

Effectively draining moisture out off an enclosure.

Prevents damages, such as condensation water.

Allows the air inside the enclosure to breathe with the surrounding atmosphene.

Cap/Body Material	Brass, Brass Nickel Plated, Stainless Steel
Seal Material	Silicone
Application	Zone 1, Zone 21, Zone 2, Zone 22
Equipment Group	Group II, Group III
Equipment Marking	EX II 2GD Ex eb IIC Gb, Ex tb IIIC Db
Ingress Protection Rating	IP66
Temperature Range	-60°C to +85°C
Thread Type	Metric, NPT
	Other thread types available upon request.
Accessories	Lock nuts, Gaskets (Washers)
Remarks	All accessories must be ordered separately.
	Standard marking includes ATEX, IECEx and Group II,III info.
	For other special certificate marking requests, please contact us.
	Some approvals do not cover all sizes, check datasheets for details.
	Other thread types available upon request.
Certificates
ATEX Approval	IMQ 13 ATEX 030X
ATEX Standards	EN 60079-0, 7, 31
IECEx Approval	IECEx IMQ 14.0003X
IECEx Standards	IEC 60079-0, 7, 31
TR CU (EAC)	No TC RU C-TR.AA87.B.00941
TR CU standards	ГОСТ 31610.0; ГОСТ IEC 60079-7, 31
UL Certificates	E350312
UL Standards	UL 508A, UL 50E, CAN/CSA C22.2 No. 14-2010
INMETRO	DNV 21.0185 X
INMETRO Standards	ABNT NBR IEC 60079-0, 7, 31
Marine Approval	TAE00003WU
UKCA	CML 21UKEX3475X

NPT

		Datasheet	3D File	Ordering Code
